Pattern Characteristic
● Horizontal and deep trench excavation pattern provide tyre excellent drive and brake performance.
● Deepen the transverse shoulder wide open pattern groove design, to provide good self-cleaning.
● Deepen the pattern to increase mileage.
● The shoulder and decorative pattern between blocks design of the strong gluten, effective Inhibition of pattern block root fissure.
Accepatable Tyre Position
Technical Specifications
| Tire Size | 11.00R22.5 | 12.00R24 | |
| Ply | 16 | 18 | |
| Load index | 148/145 | 158/155 | |
| Maximum load（kg) | Single tire | 3150 | 4250 |
| Double tire | 2900 | 3875 | |
| Corresponding air pressure(kpa) | Single tire | 850 | 830 |
| Double tire | 850 | 830 | |
| Measurement Wheel rim | 8.25 | 8.50 | |
| Allow using wheel rim | 7.50 | 9.5,8.50V | |
| Decorative pattern Depth(mm) | 24 | 30 | |
| New tire design size(mm) | Section width | 279 | 315 |
| Outer diameter | 1054 | 1238 | |
