Pattern Characteristic
● Horizontal pattern provide tyre excellent drive and brake performance.
● Pattern block stiffener, effectively restrain grinding block root tear and decorative pattern.
● Shoulder pattern groove and open pattern design, good tire heat dissipation.
● Tiny groove pattern block increase the wet resistance of the tire.
Accepatable Tyre Position
Technical Specifications
| Tire Size | 225/70R19.5 | 245/70R19.5 | |
| Ply | 12 | 16 | |
| Load index | 125/123 | 135/133 | |
| Maximum load（kg) | Single tire | 1650 | 2180 |
| Double tire | 1550 | 2060 | |
| Corresponding air pressure(kpa) | Single tire | 660 | 830 |
| Double tire | 660 | 830 | |
| Measurement Wheel rim | 6.75 | 7.50 | |
| Allow using wheel rim | 6.00 | 6.75 | |
| Decorative pattern Depth(mm) | 14.5 | 15.5 | |
| New tire design size(mm) | Section width | 226 | 248 |
| Outer diameter | 811 | 839 | |
